RE-I-18-8-DAO inductive sensor

SKU: NPN NO, 3 Wire
Description

Installation : NON-FLUSH Sensing distance : 7mm Standard sensing target : 20×20×1mm(iron) Response frequency : 250Hz

Technical Specifications

Download Catalog
Inductive Data
Switching function Normally open (NO)
Switching Distance 8mm
Installation NON-FLUSH
Hysteresis(distance) Max. 10% of sensing distance
Output NPN NO
Electrical Data
Supply Voltage 6..36V DC
Current Consumption (Ub = 24 V) < 12mA
Response Frequency 250Hz
Temperature Drift < 10%
Temperature Range -30 ... 65u00b0C
Switching Output voltage Drop < 1V
Operating current 300mA
Residual Current Switching Output < 100u00b5A
Switching state indicator LED, Red
Short Circuit Protection yes
Overload Protection yes
Reverse polarity protection yes
Standard and Certeficate
Mounting
Dimensioned picture
